V920EX

The V920EX vertical lathe increases productivity by providing stable machining of thin and odd-shaped workpieces. With a max turning diameter of 920 mm and max turning height of 860 mm, this machine is capable of performing powerful, heavy-duty cuts, while the vertical orientation is the ideal platform for running thin-walled parts without distortion. The box-type base and column make a highly dependable, highly rigid structure and the headstock with flange construction minimises the effects of thermal deformation and vibration – ensuring stable accurate cutting. The base is designed for smooth chip flow, and the optional chip conveyor can be placed for side or rear disposal to meet shop requirements. The ergonomical design includes easy access to the chuck and a front-skirt operation panel convenient for up-close jobs in addition to the swiveling pendant operation panel.

Categories: , ,

Technical Specifications

[ ] Optional

Max. turning diameter [mm]
920
Max. turning length [mm]
860
Spindle speed [min-1]
1,250
No. of tools
12
Motor [kW]
30/22
Features
M, ATC

Download Brochure

Please download the latest brochure for more information & full technical specification
