MU-V Series

The UNIVERSAL CENTER MU-V Series provides the power of process-intensive machining and high-speed, high-accuracy cutting through the combination of turning and 5-axis multitasking machining. The fast yet powerful trunnion table allows simultaneous 5-axis machining and one-chuck multi-sided machining of complex shapes. Ideal for die and mould shops and highly complex aerospace components.

Make an Enquiry

TECHNICAL SPECIFICATIONS

MACHINES:

  • Table size [mm]
  • Axis travel [mm]
  • Spindle speed [min-1]
  • No. of tools
  • Motor [kW]
  • Features

MU-400VIII

  • Table size [mm] : Ø 400
  • Axis travel [mm] : X: 762 / Y: 460 / Z: 460
  • Spindle speed [min-1] : 8,000 [15,000], [20,000], [25,000], [35,000]
  • No. of tools : 20 [32], [48], [78], [104], [156], [208], [234], [338]
  • Motor [kW] : 11/7,5 [15/11], [22/18,5], [30/22], [15]

MU-500VIII

  • Table size [mm] : Ø 500
  • Axis travel [mm] : X: 1,050 / Y: 560 / Z: 460
  • Spindle speed [min-1] : 8,000 [15,000], [20,000], [25,000], [35,000]
  • No. of tools : 20 [32], [48], [64], [98], [132], [166], [200], [234], [268]
  • Motor [kW] : 11/7,5 [22/18,5], [30/22], [15/11], [15]

MU-4000V

  • Table size [mm] : Ø 400
  • Axis travel [mm] : X: 740 / Y: 460 / Z: 460
  • Spindle speed [min-1] : 15,000 [12,000], [20,000], [25,000]
  • No. of tools : 32 [48], [64], [98], [132], [160], [200], [234], [268]
  • Motor [kW] : 22/18,5 [30/22], [15/11]
  • Features : L (Turning spec.), APC, Connectable with Standroid

MU-5000V

  • Table size [mm] : Ø 500
  • Axis travel [mm] : X: 800 / Y: 1,050 / Z: 600
  • Spindle speed [min-1] : 10,000, 6,000 [8,000], [15,000], [20,000], [25,000]
  • No. of tools : 32 [48], [64], [98], [132], [166], [200], [234], [268]
  • Motor [kW] : 11/7,5 [15/11], [22/18,5]
  • Features : L (Turning spec.), APC

MU-6300V

  • Table size [mm] : Ø 630
  • Axis travel [mm] : X: 925 / Y: 1,050 / Z: 600
  • Spindle speed [min-1] : 10,000, 6,000 [8,000], [15,000], [20,000], [25,000]
  • No. of tools : 32 [48], [64], [98], [132], [166], [200], [234], [268]
  • Motor [kW] : 11/7,5 [15/11], [22/18,5]
  • Features : L (Turning spec.), APC

MU-8000V

  • Table size [mm] : Ø 800 x 630
  • Axis travel [mm] : X: 925 / Y: 1,050 / Z: 600
  • Spindle speed [min-1] : 10,000, 6,000 [8,000], [12,000], [15,000], [20,000], [25,000]
  • No. of tools : 32, [64], [98], [132], [166], [200], [234], [268]
  • Motor [kW] : 11/7,5 [15/11, 22/18,5]
  • Features : L (Turning spec.), APC
