Technical Specifications
[ ] Optional
Features
Connectable with MB-46V, MB-56V, GENOS M460V, GENOS M560V, GENOS L3000, MU-S600V, MU-4000V, Collision Avoidance System
Control axis
6 axis (J1, J2, J3, J4, J5, J6)
Max. payload
5kg/ 10kg
Max. working range
1,440mm
Repeatability
+/- 0.06mm
Environmental specification
Main axis IP65
End effector stocker
3 End effector
Distance Between Centers
mm
400 or 650
Max Grinding Dia.
mm
Ø200
Grinding Wheel ODxID
mm
Ø610 × Ø254
Max Grinding Wheel Width
mm
150
Rapid Traverse:X
m/min
30cc
Rapid Traverse:Z
m/min
20
Wheel Spindle Motor
kW
7.5 [15]
