Technical Specifications
[ ] Optional
Table size [mm]
1,500 x 3,000 to 3,000 x 12,000
Distance between columns [mm]
2,150 to 3,650
Spindle speed [min-1]
4,000, [6,000], [8,000], [10,000], [20,000]
No. of tools
50, [80, 100, 120, 180, 240, 360]
Motor [kW]
43/37
Axis travel [mm]
X: 3,200 / Y: 2,600 / Z: 800 to X: 12,200 / Y: 4,100 / Z: 1,200
Features
APC, AAC
