Technical Specifications
[ ] Optional
Table size [mm]
1,500 x 3,000 to 3,000 x 12,000
Distance between columns [mm]
2,150 to 3,650
Spindle speed [min-1]
4,000 [6,000, 10,000]
No. of tools
50, [80], [100], [120], [180], [240], [360]
Motor [kW]
26/22
Axis travel [mm]
X: 3,200 / Y: 2,600 / Z: 800 to X: 12,200 / Y: 4,100 / Z: 1,200
Features
APC, AAC
